Smart Modular UPS RM FM series 100-1200KVA

The Modular UPS is a high-performance, scalable power protection solution designed for critical applications. Featuring full DSP digital control, advanced component-level protection, and a user-friendly 10-inch color touchscreen, it ensures maximum reliability and ease of use. With intelligent self-diagnostics, flexible battery configurations, and support for capacities up to 3.2MW, it is ideal for data centers, government, finance, telecom, healthcare, and other demanding environments.

POWER RANGE

100-1200kva

POWER PHASE

3/3 phase



Category:

APPLICATION

This product has been widely used across various industries such as government, finance, telecommunications, education, transportation, meteorology, broadcasting, commerce and taxation, healthcare, energy, and electric power.

Product Features

  • Full digital control with DSP: All power conversion stages including rectification, inversion, charging, and discharging are fully digitally controlled
  • Component-level protection for extreme reliability and enhanced environmental adaptability.
  • Ultra-large color LCD touchscreen – 10-inch LCD touch display with graphical interface for easy operation and user-friendly interaction.
  • Intelligent system self-diagnosis with extensive fault logs and large-capacity historical data storage.
  • Maximum capacity supports up to 3.2MW, making it the optimal choice for ultra-large data centers.
Model RM600/100 RM800/100 RM1000/100 RM1200/100
Capacity 600kVA/600kW 800kVA/800kW 1000kVA/1000kW 1200kVA/1200kW
Main Input Input Phases 3-phase + N + PE
Input Voltage 380/400/415VAC (line) / 220/230/240VAC (phase)
Input Frequency 50/60Hz
Power Factor >0.99
Current THD THDi < 3% (100% linear load)
Voltage Range 304-478VAC (line) full load; 304-228VAC (line) linear derating from 100% to 50% load
Frequency Range 40-70Hz
Battery Battery Voltage 3-wire: ±240VDC (30-50 cells configurable)
Optional 2-wire: 480VDC (30-50 cells configurable)
Charging Power 20% of rated power
Bypass Bypass Voltage 380/400/415VAC (line); 220/230/240VAC (phase)
Voltage Range Configurable, default -20%~+15%; upper limit: +10%, +15%, +20%, +25%; lower limit: -10%, -15%, -20%, -30%, -40%
Overload Capacity 110% continuous
101%≤load<125%, ≤5min
125%≤load<150%, ≤1min
>150%, 1s
Output Rated Output Voltage 380/400/415VAC (line); 220/230/240VAC (phase)
Rated Frequency 50/60Hz
Output Power Factor 1
Voltage Accuracy ±1.0%
Output Dynamic Response <5% (20%~80%~20% step load)
Recovery Time <20ms (0%~100%~0% step load)
THDu 1% (linear load); <5% (non-linear load)
Inverter Overload 110% for 1 hour, then bypass
125% for 10 minutes, then bypass
150% for 1 minute, then bypass
>150%, 200ms then bypass
Frequency Accuracy ±0.1%
Tracking Range Configurable, ±0.5Hz~±5Hz, default ±3Hz
Tracking Rate Configurable, 0.5Hz/s~3Hz/s, default 0.5Hz/s
Crest Factor 3:1
Phase Accuracy 120° ± 0.5°
System Efficiency AC mode >97%; Battery mode >97%
Display LCD + LED + 10″ color touchscreen
Safety Standards IEC62040-1, IEC60950-1
EMC IEC62040-2; IEC62040-2(2ESD); IEC61000-4-3 (RS); IEC61000-4-4 (EFT); IEC61000-4-5 (Surge)
Protection Level IP20
Standard Interfaces USB, RS232, RS485, Dry contact card, Battery cold start, Anti-theft net
Optional Accessories SNMP card, Extended dry contact card, Parallel kit, Surge protection, APP/WiFi/Bluetooth
Operating Environment 0–40°C (operating); -25°C to 70°C (storage); 0–95% RH (non-condensing)
Noise (dB) at 1m 72dB @ 100% load, 68dB @ 45% load
Dimensions Cabinet (W*D*H) mm 800×1000×2000 1200×1100×2000
Module (W*D*H) mm 475×705×140
