Uninterruptible power supply replacement Batteries RM-GFM series

Keep your backup power system running reliably with high-quality replacement UPS batteries. Designed to meet or exceed OEM specifications, our sealed lead-acid batteries ensure uninterrupted protection for your critical electronics.

  • Adopts AGM (Absorbent Glass Mat) valve-regulated sealed technology.
  • The battery uses high-strength ABS material for the tank and cover.
  • Boasts a wide temperature tolerance range from -15°C to 45°C.
  • The optimal operating temperature is around 20°C with a tolerance of ±5°C.
  • Ensures zero leakage, offering a secure and reliable usage experience.
  • Can be installed either vertically or horizontally, facilitating convenient transportation and installation.
  • Features high sealing reaction efficiency, resulting in minimal water loss. There’s no need to add distilled water or electrolyte during use, simplifying maintenance.
  • Exhibits a low self-discharge rate.
Category:

2V IDC SERIES UPS batteries

MODEL Rated Voltage Capacity (C10/25°C) Dimensions (mm) Net Weight
L W H TH
RM-BA02300 2V 300AH 176 156 330 365 18.2Kg
RM-BA02400 2V 400AH 211 176 330 365 24.5Kg
RM-BA02500 2V 500AH 243 174 330 365 28.7Kg
RM-BA02600 2V 600AH 302 176 330 339 34.2Kg
RM-BA02700 2V 700AH 302 176 330 339 37Kg
RM-BA02800 2V 800AH 411 175 331 339 47.5Kg
RM-BA021000 2V 1000AH 479 175 330 339 57.5Kg
RM-BA021200 2V 1200AH 479 175 330 339 62Kg
RM-BA021500 2V 1500AH 404 355 343 350 87Kg
RM-BA022000 2V 2000AH 492 352 341 350 115.5Kg
RM-BA023000 2V 3000AH 710 352 338 356 178Kg

12V IDC SERIES

MODEL Rated Voltage Capacity (C10/25°C) Dimensions (mm) Net Weight
L W H TH
RM-BA1224 12V 24AH 175 166 125 125 6.7Kg
RM-BA1238 12V 38AH 197 166 173 173 11.2Kg
RM-BA1265 12V 65AH 350 165 173 173 18.6Kg
RM-BA12100 12V 100AH 330 172 213 221 28.0Kg
RM-BA12120 12V 120AH 407 173 208 232 32.5Kg
RM-BA12150 12V 150AH 480 170 239 242 40.0Kg
RM-BA12200 12V 200AH 522 239 220 228 57.0Kg
RM-BA12250 12V 250AH 520 268 220 226 67.5Kg

12V STANDARD SERIES

MODEL Rated Voltage Capacity (C10/25°C) Dimensions (mm) Net Weight
L W H TH
RM-BA1224Z 12V 24AH 175 166 125 125 6.5Kg
RM-BA1238Z 12V 38AH 197 166 173 173 10.7Kg
RM-BA1265Z 12V 65AH 350 165 173 173 16.9Kg
RM-BAI2100Z 12V 100AH 330 172 213 221 27.0Kg
RM-BA12120Z 12V 120AH 407 173 208 232 31.8Kg
RM-BA12150Z 12V 155AH 480 170 239 242 39.2Kg
RM-BA12200Z 12V 200AH 522 239 220 228 54.0Kg
RM-BA12250Z 12V 250AH 520 268 220 226 64.8Kg

12V STANDARD SERIES

MODEL Rated Voltage Capacity (C10/25°C) Dimensions (mm) Net Weight
L W H TH
RM-BH12100 12V 360W/100AH 330 173 213 16 30Kg
RM-BH12120 12V 460W/120AH 408 177 225 225 37.5Kg
RM-BH12150 12V 560W/145AH 483 170 238.5 239 46.5Kg
RM-BH12180 12V 650W/180AH 532 207 214 220 56.5Kg
RM-BH12190 12V 705W/190AH 532 207 214 220 59Kg
RM-BH12195 12V 750W/195AH 503 212 226.5 234.5 61Kg
RM-BH12200 12V 800W/200AH 503 212 226.5 234.5 62.8Kg
RM-BH12225 12V 845W/225AH 496 259 227 233 74.5Kg
RM-BH12235 12V 890W/235AH 496 259 227 233 77Kg

12V GEL BATTERY SERIES

MODEL Rated Voltage Capacity (C10/25°C) Dimensions (mm) Net Weight
L W H TH
RM-BA1238J2 12V 38AH 197 166 173 173 11.8Kg
RM-BA1265J2 12V 65AH 350 165 173 173 21.2Kg
RM-BA12100J2 12V 100AH 407 173 208 232 32.1Kg
RM-BA12120J2 12V 120AH 407 173 208 232 35.0Kg
RM-BA12150J2 12V 155AH 480 170 239 242 45.0Kg
RM-BA12200J2 12V 200AH 522 239 220 228 62.0Kg
RM-BA12250J2 12V 250AH 520 268 220 226 72.0Kg
